5080 Power Unit
5080 高壓發生器是大部分Takker交流祛靜電
系統的動力系統來源，它為祛靜電幫，吹風機
及噴風槍等提供高壓電源以產生電離子。
The 5080 Power Umit is the heart ofmost
F raser AC stratic eliminators In supplies the
high voltage which produces the ionisation in
most Takker Bars, Blowers.Guns etc.
5080產生一個受控制及安全的高壓低流量電流
The 5080 produces high voltage, low cur
rent in a controlled andsafe way.
它最多可連接4個祛靜電器
t has connections for up to four static eliminators.
結構： 噴粉涂層金屬外殼
Construchion:Powder coated steel case.
輸出： 5.5千伏于5毫安（最大）全密封輸出線組
Output: 5.5kV at 5mA max.
Totally encapsulated windings..
輸入：可按要求配置115伏 50/60Hz或 230伏 50/60Hz
或開關式雙輸入，主電源開關連保險IEC插座連2米主線
Input: 115V 50/60HZ or 230V 50/60Hz.Please specify
Switchable model also avaitable
Illyminated mains switch and fuse
IEC conneetor and 2m mains cable
負荷: 最大負荷:
2000棒及配置 祛靜電幫及高壓連接線最大總長度為12米
4000電離子噴風槍 一支槍加10米連線或兩支槍加5米連線
Load Maximum load :
2000 Bar and derivatives: 12m of combined Bar and HT cable
4000 lonised Airgun: 1 Gun with 10m HT cable or 2 Guns with 5ms Htcable
安全
Safety 電流之上限為5毫安，具有安全過載保護，并在安全情況下自動重新起動
The design is cyrrent limited to 5mA ,lf more current is drawn then the windings will shut down.
Power will restart when the excessive load is removed.
|
